Cutting Plotter and Thermopress

A cutting plotter is actually a printer with a sharp blade instead of a printing head. It cuts the upper layer of double-layered materials. It is therefore perfect for the creation of stickers and iron-on patches. At FabLab we have a Roland GS-24 cutting plotter and Transmatic TMH-28 E thermopress, which is able to deal with tarpaulin up to lengths of 2.5 m. Ideally documents for the plotter should be imported in either EPS or AI formats for Illustrator 8 or lower. For the JPG or PNG formats, it is possible to use Image Outline, but success is not guaranteed.

Technical parameters

Width of the inlet material
50 - 700 mm
Maximum working area
width: 584 mm length: 25 000 mm
Cutting speed
10 - 500 mm/s in all directions
Contact force of the blade
30 - 350 gf (gram-force)
Mechanical resolution
0.0125 mm/stride
Software resolution
0.025 mm/stride
Cut Studio
Import options
EPS, AI – it has to be saved in a format suitable for Illustrator 8 or lower PNG/JPG - Image Outline can be used
